KHT14000 Type Casing Power Tong

description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Product Description

The KHT (KT) hydraulic power tongs are open-type power tongs applicable for making up and breaking out oil casing pipes during oil field workover operations.They featurehighoperating eiciency, significantly reducethelabor intensity of workers, improve the quality of pipe string thread connections, and reduce pipe string accidents caused by improper workover operations.
The front two-jaw-plates of the master tong are in the swing structure and the back jaw plate is the roller-climbing structure. The assembly and disassembly is very convenient. The optimum tangent-diameter ratio design ensures reliable clamping and easy slope retreating.The back tong is the three-jaw-plate structure pushed by hydraulic cylinder. The structure is simple and the clamping is reliable.
Four-gear rotation is adopted for large speed regulation range. And the rated torque is large.
It has the braking mode with braking staple.The braking torque is large.The operation is simple.And it is convenient for repair and replacement.
With the open large gear suporting structure, hardness and rigidity of open large gear is enhanced considerably:
The shellis made of stel plate with high hardness.The overall hardness isgood. Various jaw plates are made with fine casting and forging process. It has beautiful apearance and high hardness.
Hydraulic torque indicator is provided. And installation interface of turning torque instrument is provided for computerized management.
The KHT14000 casing power tong is suitable for unloading pipe string threads during casing operations in oil fields and mines. It has high operating efficiency, greatly reduces the labor intensity of workers, improves the quality of casing string thread connections, and reduces casing string accidents caused by improper casing operations.

Characteristic:
The torque range is large, with a maximum torque of up to 100KN. m; 1,
Open type, quick and convenient to enter and exit the working position, with good strength and rigidity of the integrated clamp head: 3 swing type double jaw plate clamp head, extremely easy to disassemble and assemble, good cutting diameter ratio design, ensuring stable clamping and easy slope retreat;
Adopting four speed settings, with a wide speed range and high rated torque; The brake band braking method has a large braking torque, simple operation, and is easy to maintain and replace. The large notch gear support structure greatly improves the strength and stiffness of the combined large gear. The fully hydraulic type adopts mechanical shifting, and the structure is simple and stable; The shell is made of high-strength steel plate, which increases its strength. Each jaw plate adopts precision casting technology, with beautiful appearance and high strength; Equipped with a hydraulic torque indicator and a torque meter installation interface for easy computer management; 10. Adopting a dual soft axis safety door safety device with good safety performance;

Technical Parameters:
1.Applicable Pipe Diameter Range:Main Pliers 4-14″    Back-Up Tong 4-15 1/2″
2.Maximum Torque:
High-Grade:13.5kN.m
Secondary High End:27kN.m
Next Lowest Gear:48kN.m
Low End:100kN.m
3.Clamp Head Rotation:
High-Grade :24rpm
Secondary High End:11rpm
Next Lowest Gear:7rpm
Low End:3rpm
4.Rated Pressure:15MPa
5.Work Flow:187.5 L/min
6.Dimensions (Length x Width x Height):1750x1100x2060 mm
7.Weight:2600 kg(Including Hydraulic Lifting Cylinder)


Application Scenarios
